Twin Asansör Yolcu Asansörleri
Perfect choice for tailored vertical transportation solutions, handling both passenger and freight applications, with a lift capacity of up to 26 feet.
Bu ürün için en uygun fiyat teklifini almak için bizimle iletişime geçin.
Teklif İsteTeknik Özellikler
| Model | Ηydraulic Twin Piston Holeless (HAD) |
| Rated Load (Per Platform) | up to 4000lbs (1816 kg)(per platform) |
| Suspension | 1:1 |
| Machine Room | MRL (MR) |
| Max Travel (m) | up to 24' – 0 3/4" (7334mm) |
| Max Number of Stops | 3 |
| Max Speed (m/s) | up to 100fpm (0,5m/s) |
| Min Pit Depth (mm) | 4' - 0" (1219mm)/ 5' - 0" (1524mm) |
| Minimum Total Overhead Height | 11' - 10 7/8" (3625mm) |
| Maximum car entrances | 2 |
| Complies with | ASME A17.1 code |
Ürün Açıklaması
Perfect choice for tailored vertical transportation solutions, handling both passenger and freight applications, with a lift capacity of up to 26 feet.
